Clover Electronics offer customizable PCB solutions to meet the specific needs of our customers, and our expertise in the industry ensures that we can provide high-quality solutions to a variety of industries.

Rigid PCB Assembly
Rigid PCB Assembly

From quick-turn prototypes through volume production with schedule sharing delivery programs, Clover Printed Circuit Board (PCB) assembly operation is ready to handle all of your assembly needs. We utilize a common equipment platform for SPI, Placement, Reflow, and AOI ensuring that transition from prototype to production is seamless. Our state-of-the-art technology is fast, accurate and repeatable, with every PCB assembly is manufactured in compliance with IPC-610 Class II or III acceptability criteria.

Flexible Circuit Assembly
Flexible Circuit Assembly

Flexible circuit boards have grown in popularity to accommodate tight electronic packages and electrical connections where board thickness or flexibility is a factor. To meet this need, Clover offers flexible circuit board assembly services. Our Design for Manufacturing (DFM) support capabilities combined with our state-of-the-art equipment enable us to assemble flexible circuit boards to meet all environmental and performance specifications.

Through-Hole Technologies
Through-Hole Technologies

Supporting legacy product is a core competency for Clover. We have machine placement capabilities to support axial, radial, and dip packages. The idea is to auto-insert everything that we can, minimizing handling and building quality into the product that we supply. For those parts that do not lend themselves to automation, our experienced operators are  trained on the latest soldering techniques.

●  Axial, Radial, DIP Auto Insertion                ●  Side Lines

●  Mechanical Insertion Equipment               ●  Selective Wave, (RoHS and SnPB)

●  Sequencing                                                ●  Wave Solder (RoHS and SnPB)



SURFACE-MOUNT Technologies
SURFACE-MOUNT Technologies

We offer surface-mount assembly with components of any size, from 01005 passive parts to large quad flat packs (QFPs) and ball grid arrays (BGAs). Our surface-mount assembly processes are tightly controlled and monitored from solder paste stenciling to pick and place, and through reflow.

Utilizing multiple surface-mount assembly lines, we can build a simple, single-sided board with just a few components or large double-sided boards with thousands of components.

High-speed Production Lines
10

High-speed Production Lines

DIP Production Lines
5

DIP Production Lines

On-line AOI Inspection
100%

On-line AOI Inspection

Projects Done
280K+

Projects Done

Clover

Products

Clover provides a comprehensive range of services for Printed Circuit Board Assembly that enable our customers to fully realize their designs. With vast experience working across a diverse range of innovative industries, such as Industrial, Medical, Intelligence, Communication, and many others, we are well-equipped to handle any project.

Although we are unable to disclose specific details about the printed circuit boards shown below due to confidentiality agreements with our customers, they serve as just a few examples of the kind of work we can deliver. If you have any queries about a potential project or any general questions about 1Link, please do not hesitate to get in touch with us.

  • Automotive Industry
    1
    2
    3
    4
  • Communication
    1
    1
    1
    1
  • Industrial Electronics
    1
    1
    1
    1
  • PCB Assembly

    Inspection&Test

    Inspection
    of PCB assembly
    Inspection of PCB assembly
    Inspection of PCB assembly
    To ensure the delivery of high-quality and dependable PCB assemblies, it is essential to perform inspections at various stages of the manufacturing and assembly process in order to eliminate surface defects.

    This involves assessing the design and manufacturing processes to determine their compliance with specified or general requirements, based on professional judgment.

    Inspections for printed circuit boards can be customized to meet the specific requirements of each client.

    Timely and professional inspections play a crucial role in identifying defects prior to electrical testing and gathering data for Statistical Process Control (SPC).

    Given the widespread use of Surface Mount Technology (SMT) in PCB assembly, inspections become even more vital due to the increased stress that SMT solder joints must endure compared to those using Plated-Through-Hole (PTH) technology.

    As SMT devices rely on the structural integrity of solder joints to remain securely attached to the board, conducting thorough inspections is paramount to ensuring the long-term electrical reliability of circuit boards.

    Testing and analysis are crucial processes during PCB assembly. Multiple tests are required to ensure the proper functioning of the fabricated board.

    It is a nightmare for any company to discover that a faulty board fails to power on.


    To ensure the optimal performance of the final product, thorough testing is essential in electronic production.

    This is why the industry employs various testing methods and processes to ensure the correct fabrication and desired functionality and capacity of PCBs.


    The following are some of the testing methods commonly used during PCB assembly:

    In-Circuit Testing             Automated Optical Inspection (AOI)         X-Ray Inspection

    Flying Probe Testing        Burn-In Testing                                         Functional Testing

    Testing Methods During PCB Assembly
    Testing Methods During
    PCB Assembly
    Testing Methods During PCB Assembly

    More

    Equipments

    Flying Probe Testing

    Flying Probe Testing

    In Circuit Testing

    In Circuit Testing

    Burn-in Testing

    Burn-in Testing
